E-BHF-M Series”High-Flow” Type Pleated Depth Media Filter Cartridges for Bag Housings
Endoer™ E-BHF-M series pleated depth media cartridges provide efficient micronic and submicronic retention of particulate in high-purity fluid filtration applications. Available in both polypropylene (PP) and micro-glass (MG) m...
Endoer™ E-BHF-M series pleated depth media cartridges provide efficient micronic and submicronic retention of particulate in high-purity fluid filtration applications. Available in both polypropylene (PP) and micro-glass (MG) media and in a wide range of absolute and nominal ratings. Compatible fit with most common bag filter housings. They offer fine flow permeability and a high contaminant capacity with excellent chemical resistance. Component materials comply with US FDA and EU regulations for safe use with food products and potable water.
Retention Level Options
Select from four levels of design efficiency to deliver the desired balance between retention,service life,and economy.
Absolute +/99.98%for maximized retention
Absolute/95%
Nominal/80%
Water Grade 60%for maximized life and economy
Features
Inside-to-out flow traps particulate inside the cartridge
Provides several times the filtration area of bags
Durable and inert polypropylene media & components
Micro-glass media option offers higher permeability and more efficient retention
Compatible fit with most common bag filter housings
Thermally-bonded construction for cartridge integrity
Applications
Beer, wine, distilled spirits, bottled water
Food products & ingredients
RO prefiltration
Process water; wastewater
Fine chemicals
Product Quality
Produced in a clean-room environment for product purity & cleanliness.
Manufactured within an ISO 9001:2015 certified quality management system
Each filter element is inspected for compliance with requirements for manufactured cartridge integrity.
Plastic components meet Biological Reactivity Test requirements of USP <88> for Plastics Class VI-121°C.
